29
Function Range Max. input
AC current 10 A
DC current 10 A
Function Range Input protection
AC voltage 45 Hz ... 1000 Hz 1000V AC rms or 1000V DC
AC+DC voltage 50 Hz ... 400 Hz 600V AC rms or 600V DC
LOW Z voltage AC/DC 50 Hz ... 400 Hz 600V AC rms or 600V DC
DC voltage 50 Hz ... 400 Hz 600V AC rms or 600V DC
Resistance, capacitance, diode
check, continuity, temperature
600V AC rms or 600V DC
All accuracy ratings in AC ranges are specified for 5%...95% of measured value
Diode test
Test current/voltage 1 mA /
open circuit voltage < 3 V DC typical
Continuity test Response threshold < 30Ω, Test current < 1 mA
LCD 0 … 6000
Measurement range 3 measurements/sec.
Input resistance 10 MΩ (VDC, VAC, V AC+DC), 3 kOhm (VDC Low Z, VAC Low Z)
Protection class II, double insulation
Overvoltage category CAT III - 1000V, CAT IV - 600V
Pollution degree 2
Operating conditions 0 ... 40°C, 75%rH, no condensation, max. altitude 2000 m
Storage conditions -10 ... 60°C, 80%rH, no condensation
Radio module operating data
Bluetooth LE 4.x interface
Frequency band: ISM band 2400–2483.5 MHz, 40 channels
Transmission power: max. 10mW
Bandwidth: 2 MHz
Bit rate: 1 Mbit/s; Modulation: GFSK/FHSS
Power supply 4 x AAA 1.5 Volt batteries
Dimensions (W x H x D) 75 x 170 x 48 mm
Weight (incl. batteries) 416 g
EU directives and disposal
This device complies with all necessary standards for the free
movement of goods within the EU.
This product is an electric device and must be collected separately
for disposal according to the European Directive on waste electrical
and electronic equipment.
Further safety and supplementary notices at:
http://laserliner.com/info?an=mumexp
