LAUNCH 440(440W) 455(455W) Installation Manual
28
424
103201507
Drive on ramp bar
426 201020706 Drive ramp
427 201020691 Side slip plate assembly
428 104080008 Ball seat
431 104080007 Ball
429 201020694 Cover of side slip plate
430 201020690 Fixing pin
Diagram of hydraulic system:
6
2
4
1
5
M
3
7
8
P
11
9
1.GearPump2.Motor3.Filter4.Check-Valve
5.SafetyValve6.ReleaseValve7.FlowControlValve
9.Cylinder10.OilLevelGauge
