LAUNCH X-431 V+ V4.0 User Manual
5
off.
• Press it once to turn off the LCD if the LCD
lights up.
• Press and hold it for 3 seconds to turn it off.
• Press and hold it for 8 seconds to perform
forced shutdown.
3
Volume +/-
Adjusts the system volume.
4
Speakers
Support sound play
5
Front Camera
Support taking photographs
6
USB/Charging
Port
• To connect to AC outlet for charging.
• To connect to PC for data exchange.
7
Microphone
Support sound signal transmission
8
Rear Camera
Support taking photographs
9
Adjustable stand
Flip it out to any angle and work comfortable at
your desk, or hang it on steering wheel.
1.3.2 VCI connector (Only for Passenger Vehicle Configuration)
The VCI works as a vehicle communication interface device, which is used to
connect to the vehicle’s DLC (Data Link Connector) socket directly or via OBD II
extension cable to read the vehicle data and then send it to the tablet via
Bluetooth.
It is pre-installed in the docking slot on the back of the display tablet. Use the
hand to press the VCI once, it will be automatically ejected from the docking slot.
When it is not in use, please reinsert it into the slot to avoid loss.
