LED LED Status Status of the Instrument
flashing
gr
een
iCON gps 70 is in base mode, RTK data is
transmitted to the selected port. Rate
according to RTK base setting.
RTK Rover
LED
off iCON gps 70 is in RTK base mode or
iCON gps 70 is switched off.
green iCON gps 70 is in rover mode, no RTK data is
received via selected port.
flashing
green
iCON gps 70 is in rover mode, RTK data is
received via selected port. Rate according to
received correction data.
Connectivity
LED
off iCON gps 70 is not powered or module is not
ready.
green Bluetooth is in data mode and ready for con-
necting.
blue Bluetooth has connected.
Storage LED off No SD card is inserted or iCON gps 70 is
switched off.
green SD card is inserted but no raw data is being
logged.
flashing
green
Raw data is being logged. More than 50 MB
of memory space is available on the SD card.
red Less than 50 MB of memory space is availa-
ble on the SD card.
flashing red Raw data is being logged but less than
50 MB of memory space left on the SD card.
fast flashing
red
SD card is full or no SD card is inserted while
raw data logging is configured. No raw data
can be logged.
Battery LED off Battery is not connected, flat or iCON gps 70
is switched off.
green Power is 21% - 100%.
flashing
green
Battery is inserted. External power is connec-
ted.
red Power is 20% - 11%. The remaining time for
which enough power is available depends on
the type of survey, the temperature and the
age of the battery.
flashing red Battery is inserted with less than 20% power
remaining. External power is connected.
fast flashing
red
Power is low (<10%).
Power LED off External battery is not connected or flat or no
external power supply is connected or
iCON gps 70 is switched off.
green External power is 21% - 100%.
red External power is 20% - 11%.
40 Operation
