Leica Lino L4P1 User Manual

Message Codes
Mes sag eCo de s
Leica Lino L4P1
9
Laser LED Cause Correction
ON lights red
instrument has low power Charge Li-Ion battery or change
Alkaline batteries
OFF blinks red
Temperature alert Cool down or heat up instrument
blinks blinks red
instrument is out of self-levelling range Place the instrument almost horizontal
and self-levelling will start automatically
blinks every 3 sec lights green
Levelling lock is activated for working
without self-levelling

Leica Lino L4P1 Specifications

General

Type	Line/Point level
Certification	IEC60825-1:2014
Product color	Grey, Red
Tripod thread	1/8, 1/4, 5/8 \
International Protection (IP) code	IP54
Laser class	2
Laser diode	635 nm (\u003C 5 mW)
Maximum range	15 m
Color of laser beam	Red
Leveling accuracy (±)	0.2 mm/m
Self-leveling range (±)	3 °
Battery type	AA
Operating time	24 h
Battery voltage	1.5 V
Number of batteries supported	4
Storage temperature (T-T)	-25 - 70 °C
Operating temperature (T-T)	-10 - 50 °C

Weight and Dimensions

Width	125 mm
Height	162 mm
Weight	1170 g
