Leica Lino L4P1 User Manual

Care
Care
Never immerse the device in water. Wipe off dirt
with a damp soft cloth. Never use aggressive
cleaning agents or solvents. Treat the instrument
with the same care that you would apply to bin-
oculars or a camera. Dropping or violent shaking
of the instrument may damage it. Check the instru-
ment for any damage before using it. Check the
levelling accuracy of the instrument regularly.
Leica Lino L4P1
13

Leica Lino L4P1 Specifications

General

Type	Line/Point level
Certification	IEC60825-1:2014
Product color	Grey, Red
Tripod thread	1/8, 1/4, 5/8 \
International Protection (IP) code	IP54
Laser class	2
Laser diode	635 nm (\u003C 5 mW)
Maximum range	15 m
Color of laser beam	Red
Leveling accuracy (±)	0.2 mm/m
Self-leveling range (±)	3 °
Battery type	AA
Operating time	24 h
Battery voltage	1.5 V
Number of batteries supported	4
Storage temperature (T-T)	-25 - 70 °C
Operating temperature (T-T)	-10 - 50 °C

Weight and Dimensions

Width	125 mm
Height	162 mm
Weight	1170 g
