Need help?Do you have a question about the Leica Lino L4P1 and is the answer not in the manual?
General| Type | Line/Point level |
|---|---|
| Certification | IEC60825-1:2014 |
| Product color | Grey, Red |
| Tripod thread | 1/8, 1/4, 5/8 \ |
| International Protection (IP) code | IP54 |
| Laser class | 2 |
| Laser diode | 635 nm (\u003C 5 mW) |
| Maximum range | 15 m |
| Color of laser beam | Red |
| Leveling accuracy (±) | 0.2 mm/m |
| Self-leveling range (±) | 3 ° |
| Battery type | AA |
| Operating time | 24 h |
| Battery voltage | 1.5 V |
| Number of batteries supported | 4 |
| Storage temperature (T-T) | -25 - 70 °C |
| Operating temperature (T-T) | -10 - 50 °C |
Weight and Dimensions| Width | 125 mm |
|---|---|
| Height | 162 mm |
| Weight | 1170 g |
