Leica Rugby 100 User Manual

13
Rugby 100-1.5.0en
Technical Data
Technical Data
Rugby 100
Operating Range ................................................... 1000’ (300 meters) Diameter
Self-Leveling Accuracy ..................± 1/16” at 100 feet (± 1.5 mm at 30 meters)*
Self-Leveling Range ..................................................................................... ± 5°
Manual Grade ..................................................................................... Up to 10%
Height ........................................................................................... 7.8” (197 mm)
Width............................................................................................. 9.8” (248 mm)
Depth ............................................................................................ 6.9” (175 mm)
Weight with Batteries ................................................................ 6.5 lbs. (2.95 kg)
Rotation Speeds ....................................................................................5, 10 rps
Laser Diode ..................................................................................635 nm visible
Laser Classification............................. Class II FDA21CFR/Class 2 IEC60825-1
Operating Temperature ............................................ -4° to 122°F (-20° to 50°C)
Storage Temperature.............................................. -40° to 158°F (-40° to 70°C)
Battery Life.................................... 60 hours with alkaline/ 35 hours with NiMH**
Batteries........................................................Four D-Cell Alkaline or NiMH Pack
Environmental...........................................................................Waterproof, IP66
NiMH Battery Pack
Input voltage .......................................................................................... 7.5 VDC
Input current............................................................................................1.0 amp
NiMH Charger/Adapter
Input voltage ..............................................................100 to 240 VAC, 50-60 Hz
Output voltage ....................................................................................... 7.5 VDC
Output current....................................................................................... 1.0 amps
Polarity................................................................Shaft – negative, Tip – positive
* Increased accuracy beginning serial number 100-61500. From 23° to 95°F (-5° to 35°C). Accuracy
is derated outside this range.
** Battery life is dependent upon environmental conditions.
Specifications are subject to change without notice.

Leica Rugby 100 Specifications

General

Self-Leveling Range	±5°
Laser Class	Class 2
IP Rating	IP54
Type	Rotary Laser Level
Rotation Speed	600 rpm
Laser Diode	635 nm
