Leica Rugby 100 User Manual

3
Rugby 100-1.5.0en
Table of Contents
Table of Contents
Introduction and general
operation
....................................... 4
The Rugby 100 Operating
Instructions .................................... 4
Buttons.......................................... 6
LED Indicators............................. 8
Basic operation ......................... 10
Automatic Operation .................... 10
Manual Operation ........................ 10
Using Manual Operation with
Grade........................................... 11
NiMH Battery Pack.................... 12
Technical Data........................... 13
Rugby 100 ................................. 13
NiMH Battery Pack .................... 13
NiMH Charger/Adapter .............. 13
Warranty...................................... 14
Calibration .................................. 15
Checking Level Calibration .......... 15
To Enter Calibration Mode........... 15
Troubleshooting........................ 17
Care and Transport .................. 19
Transport ..................................... 19
Storage ........................................ 19
Cleaning and Drying Windows..... 19
Safety Directions ...................... 20
Intended Use of Instruments........ 20
Permitted uses........................... 20
Adverse uses............................. 20
Limits of Use ................................ 20
Responsibilities............................ 21
Hazards of Use ............................ 21
Laser classification ...................... 24
Labeling ....................................... 24
Electromagnetic
Compatibility (EMC)..................... 25
FCC Statement
(applicable in the U.S.) ................ 25

Leica Rugby 100 Specifications

General

Self-Leveling Range	±5°
Laser Class	Class 2
IP Rating	IP54
Type	Rotary Laser Level
Rotation Speed	600 rpm
Laser Diode	635 nm
