Lennox ECOLEAN EAC 1804SM User Manual

0251SM 5 x 6 mm
2
5 x 10 mm
2
0291SM 5 x 6 mm
2
5 x 10 mm
2
0351SM 5 x 10 mm
2
5 x 10 mm
2
0431SM 5 x 10 mm
2
5 x 16 mm
2
0472SM 5 x 16 mm
2
3 x 25+2x16 mm
2
0552SM 5 x 16 mm
2
3 x 25+2x16 mm
2
0672SM 3 x 25+2x16 mm
2
3 x 25+2x16 mm
2
0812SM 3 x 25+2x16 mm
2
3 x 35+2x16 mm
2
1003SM 3 x 25+2x16 mm
2
3 x 50+2x25 mm
2
1103SM 3 x 35+2x16 mm
2
3 x 50+2x25 mm
2
1203SM 3 x 35+2x16 mm
2
3 x 50+2x35 mm
2
1303SM 3 x 50+2x25 mm
2
3 x 50+2x35 mm
2
1403SM 3 x 50+2x35 mm
2
3 x 50+2x35 mm
2
1604SM 3 x 50+2x35 mm
2
3 x 95+2x50 mm
2
1804SM 3 x 50+2x35 mm
2
3 x 95+2x50 mm
2
3N~400V-50Hz 3N~342-462V-50Hz
32
PE L1 L2
L3
N
2.8.-ELECTRICAL CONNECTIONS
- BEFORE MAKING ANY ELECTRICAL CONNECTIONS, BE SURE THAT ALL CIRCUIT BREAKERS ARE OPEN AND SUPPLY IS OFF.
- IN ORDER TO CARRY OUT THE ELECTRICAL CONNECTIONS, FOLLOW THE ELECTRICAL DIAGRAM SUPPLIED WITH THE UNIT.
- AEH: Auxiliary Electric Heater
- The cable sections have been calculated based on a distance of 50m and variation of -10V.
Do not start the unit if the drop is greater than this.
- The wiring and circuit breakers to be mounted in the installation must comply with the Regulations in force.
- Ground wires must be properly connected and have a greater length than the phase wires.
VOLTAGE OPERATION LIMITS
POWER SUPPLY UNIT MODEL
NUMBER OF WIRES X SECTION
WITHOUT AEH WITH AEH
THREE-PHASE UNITS
400V
3N ~ 400V-50Hz + PE
EAC/EAR 0251SM TO 1804SM
MODELS VOLTAGE LIMITS
0251SM A 1804SM
2.- INSTALLATION
