LXTFF01M-IOM-1511
35
Rated impulse voltage: 2500V
Number of manual cycles: 50000
Number of automatic cycles: 100000
Software class: A
EMC test voltage: 230V~ 50Hz
EMC test current: 31mA
Distances tolerances fault
mode ‘short’ exclusion: ±0,15mm
Ball pressure test temperature: 75°C
Operating temperature: 0 .. 40 °C
Storage temperature: -10 .. +50 °C
Humidity limits: 20..80% RH (non condensing)
Casing: material: ABS + PC V0 self-extinguishing
color: signal white (RAL 9003)
Size: 132 x 87 x 23.6 mm (W x H x D)
Weight: ~265 g
CERTIFICATE OF CONFORMITY
The product complies with the following standards (EMC
2004/108/EC and LVD 2006/95/EC):
EN 60730-1 (2011)
EN 60730-2-9 (2010)
WARRANTY
In the view of a constant development of their products, the
manufacturer reserves the right for changing technical data
and features without prior notice. The consumer is guaranteed
against any lack of conformity according to the European
Directive 1999/44/EC as well as to the manufacturer’s
document about the warranty policy. The full text of warranty is
available on request from the seller.
TECHNICAL FEATURES
Power supply : 230V~ -15% +10% 50Hz or
230V~ ±10% 60Hz or
24V~ -15% +10% 50 / 60Hz
Power absorption: 1.2VA
Room temperature
Regulation range: 5.0 .. 35.0 °C (confi gurable)
Sensor type: NTC 10kΩ @ 25°C ±1%
Precision: ± 1.0 °C
Resolution: 0.1 °C
Display temp. range: -10°C .. +50°C
Differential: adjustable 0.2 .. 1.0 °C
Supply pipe temperature
Sensor type: NTC 10kΩ @ 25°C ±1%
Precision: ± 1 °C
Resolution: 1 °C
Display temp. range: 0 .. 99 °C
Differential: 2 °C
Contact rating
Fan motor: 3A @ 230V~ cosφ=1
Valves: 0.3A @ 230V~ cosφ=1
Valves (inductive load): 10VA Max load power
Remote sensor (optional): NTC 10kΩ @ 25°C ±1%
Protection grade: IP 30
Classifi cation under reg. 2013.811.EC
Class: V
Contribution to energy effi ciency: 3%
Type of action: 1
Pollution degree: 2
Equipment class: II (
)
