Operation
1. Check to ensure that access panel is securely in place.
2. Lamp should remain illuminated continuously except
during service and maintenance.
3. For optimal odor control, air handler blower should
remain on CONTINUOUSLY (thermostat fan setting in
ON position, rather than AUTO).
NOTE: If air handler does not provide a continuous low
blower speed option, an additional blower relay
should be installed. Use Lennox part number
45H03. Contact the Lennox Application Department
at 1-800-453-6669 for wiring information.
NOTE: Continuous fan operation may result in higher
humidity. If humidity levels are uncomfortably high,
fan setting should be switched to AUTO during
cooling operation.
Filter, UVA Lampholder / PCO Cartridge and
UVA Lamp Replacement
IMPORTANT
Hg -- UVA Lamp contain mercury.
Manage in accord with disposal laws.
Refer to www.lamprecycle.org or call 1-800-9LENNOX.
The Healthy Climate
®
Carbon Clean 16
®
Filter, UVA
Lampholder / PCO cartridge and UVA lamp require annual
replacement. More frequent lter replacement may be
required in applications with heavier dust or dirt loads or if
you notice a reduction in odor-removal efciency. An annual
maintenance kit is available.
Annual Maintenance Kits
The annual maintenance kits include the following:
• Healthy Climate
®
Carbon Clean 16
®
Filter (1)
• PCO cartridge (1)
• UVA lamp (1)
Order using the following kit catalog numbers:
Table 7. Maintenance Kits
Part
Description
Catalog Numbers
PCO3S-14-16 PCO3S-16-16 PCO3S-20-16
Annual
Maintenance
Kit
Y6616 Y6612 Y6608
Replacement Parts
Replacement parts are available through Lennox, see
“Figure 1. Parts Identication” on page 3 for parts
arrangement. Part description and catalog numbers are as
follows:
Table 8. Repair Parts
Part Description
Catalog Numbers
PCO3S-14-16 PCO3S-16-16 PCO3S-20-16
HC Carbon Clean
16 Filter
Y6606 Y6605 Y6604
UVA Lamp X8794
PCO cartridge
insert (Purier)
Y6621 Y6607
Lampholder
Assembly
Y6622
Power Cord
(120VAC)
49M48
Power Cord
(230VAC)
91X44
Electrical Socket 75X77
Ballast Y6620
Probe Repair Kit 16X01 16X02 16X01
Sensor Repair Kit 16X03
