TousetheDVI-ItoVGAadapterwithanexternalmonitor,dothefollowing:
1.ConnecttheDVI-ItoVGAadaptertotheDVI-Ivideooutputconnectorontheportreplicator.
2.TightenthetwoscrewsontheDVI-ItoVGAadapter.
3.ConnecttheVGAconnectoroftheexternalmonitortotheDVI-ItoVGAadapter.
Youcanadjustvideosettingstocustomizetheuseoftheportreplicator.See“Workingwiththeport
replicatorutility”onpage8
.
Note:Forthebestresults,adjusttheexternalmonitoroccasionallytorealignitssettingswiththe
videooutputoftheportreplicator.Formoreinformationabouttheadjustmentprocedure,refertothe
documentationthatcomeswithyourexternalmonitor.
UsingtheEthernetconnector
Connectastandard10Mbps/100MbpsEthernetcabletotheEthernetconnectorontheportreplicator,
andwaituntilthedeviceisfullyconguredbytheWindowsoperatingsystem.
Thetwolight-emittingdiodes(LEDs)ontheportreplicatorindicatethestatusofEthernetconnectivity.
LED
Color
Description
Active
Green
WhentheLEDison,anEthernetcableisconnectedtotheEthernet
connectorandthenetwork.
Speed
YellowWhentheLEDison,thetransmissionspeedis100Mbps.WhentheLED
isoff,thetransmissionspeedis10Mbps.
