Manuallyenablingtheaudioconnectors
Tomanuallyenabletheaudioconnectorsontheportreplicator,dependingontheoperatingsystemyouare
using,dooneofthefollowing:
FortheWindowsXPoperatingsystem:
1.Right-clickthevolumeiconinthetaskbarnoticationarea.
2.SelectAdjustAudioProperties.TheSoundandAudioDevicesPropertieswindowopens.
3.ClicktheAudiotab.
4.SelectaUSBaudioline-outdevicefromtheSoundplaybackpanel,andthenselectaUSBaudio
line-indevicefromtheSoundrecordingpanel.
FortheWindowsVistaorWindows7operatingsystem:
1.Right-clickthevolumeiconinthetaskbarnoticationarea.
2.SelectSounds.TheSoundwindowopens.
3.ClickthePlaybacktabtoselectaUSBaudioline-outdevice,andthenclicktheRecordingtabtoselect
aUSBaudioline-indevice.
Disablingthevideooutputfunction
Todisablethevideooutputfunctionoftheportreplicator,dothefollowing:
1.ClicktheLenovoUSB2.0PortReplicatorwithDigitalVideoiconinthetaskbarnoticationarea.The
pop-upmenuopens.
2.ForusersoftheWindowsXPorWindowsVistaoperatingsystem,selectOfftodisablethevideooutput
functionoftheportreplicator.ForusersoftheWindows7operatingsystem,selectAdvanced...,and
thenintheMultipledisplaysdrop-downlistbox,selectShowdesktoponlyon1orShowdesktop
onlyon2todisplayyourdesktopononetargetscreen.
Supportedrefreshrates
Thetablebelowdisplaystherefreshratessupportedatvariousresolutionsandcolordepthfortheport
replicatorvideooutput.
SN
Resolution
Refreshrates(Unit:Hz)
1640x48060,72,75,85
2720x40070,85
3800x60056,60,72,75,85
4832x624
75
5
800x48060
6848x48060
7
1024x76860,70,75,85
81152x864
75
91152x870
75
101280x72060
111280x76860,75,85
121280x80060
131280x96060,85
Chapter4.Workingwiththeportreplicator11
