Lenovo 14IRP8 User Manual

Remove the Wi-Fi card
Make sure the following FRU (or CRU) has been removed.
“Remove the lower case” on page 28
Step 1. Disconnect the battery pack cable from the system board.
Attention: Use your fingernails to pull the connector to unplug it. Do not pull the cable.
Step 2. Detach the main and auxiliary antenna cable connectors. Remove one screw and then remove the
Wi-Fi card by pulling it away from the slot.
Figure 8. Remove the Wi-Fi card
Screw specifications
Number of screws
M2.0 x L2.2 1
Go to
https://support.lenovo.com/partslookup to look up the Lenovo part number of the following replacement
part:
Wi-Fi card
Remove the touchpad board cable
Make sure the following FRUs (CRUs) have been removed.
“Remove the lower case” on page 28
“Remove the battery pack” on page 29
Step 1. Peel off the keyboard cable.
Chapter 4. Removing a FRU or CRU 31

Lenovo 14IRP8 Specifications

General

Display	14" FHD (1920 x 1080) IPS, Anti-Glare
RAM	16 GB DDR4
Storage	1 TB SSD
Graphics	Intel Iris Xe Graphics
Operating System	Windows 11 Pro
Audio	Dolby Audio, stereo speakers
Camera	720p HD Camera with Privacy Shutter
Dimensions	17.9mm
Connectivity	Wi-Fi 6, Bluetooth 5.1
Ports	HDMI 1.4b, Headphone / mic combo
