Lenovo 14IRP8 User Manual

Hinge cover
Remove the strip cover
Make sure the following FRUs (CRUs) have been removed.
“Remove the LCD module” on page 39
“Remove the hinge cover” on page 41
Step 1. Release the cable from the cable guide.
Figure 27. Release the cable from the cable guide
Step 2. Remove six screws and then remove the strip cover.
Figure 28. Remove the strip cover
Screw specifications
Number of screws
M1.6 x L4.5 6
Go to
https://support.lenovo.com/partslookup to look up the Lenovo part number of the following replacement
part:
Strip cover
Remove the LCD panel and EDP cable
Make sure the following FRUs (CRUs) have been removed.
“Remove the LCD module” on page 39
42
Hardware Maintenance Manual

Lenovo 14IRP8 Specifications

General

Display	14" FHD (1920 x 1080) IPS, Anti-Glare
RAM	16 GB DDR4
Storage	1 TB SSD
Graphics	Intel Iris Xe Graphics
Operating System	Windows 11 Pro
Audio	Dolby Audio, stereo speakers
Camera	720p HD Camera with Privacy Shutter
Dimensions	17.9mm
Connectivity	Wi-Fi 6, Bluetooth 5.1
Ports	HDMI 1.4b, Headphone / mic combo
