Figure 22. Remove the speakers
Screw specifications
Number of screws
M2.0 x L3.5 2
M2.0 x L2.5 4
Go to
https://support.lenovo.com/partslookup to look up the Lenovo part number of the following replacement
part:
Speakers
Remove the LCD module
Make sure the following FRUs (CRUs) have been removed.
“Remove the lower case” on page 28
Step 1. Disconnect the battery pack cable from the system board.
Attention: Use your fingernails to pull the connector to unplug it. Do not pull the cable.
Step 2. Peel off the two pieces of tape.
Figure 23. Peel off the two pieces of tape
Chapter 4. Removing a FRU or CRU 39
