Step 3. Disconnect the EDP cable and camera cable from the system board then detach the main and
auxiliary antenna cable connectors. Release the cables from the cable guide.
Figure 24. Disconnect the EDP cable, camera cable and antenna cable
Step 4. Rotate the LCD module to an angle of more than 90 degrees and place the computer on a flat
surface as shown. Remove four screws and then remove the LCD module.
Figure 25. Remove the LCD module
Screw specifications
Number of screws
M2.5 x L4 4
Go to
https://support.lenovo.com/partslookup to look up the Lenovo part number of the following replacement
part:
LCD module
Remove the upper case
Make sure the following FRUs (CRUs) have been removed.
40
Hardware Maintenance Manual

Lenovo 14IRP8 Specifications

General

Display	14" FHD (1920 x 1080) IPS, Anti-Glare
RAM	16 GB DDR4
Storage	1 TB SSD
Graphics	Intel Iris Xe Graphics
Operating System	Windows 11 Pro
Audio	Dolby Audio, stereo speakers
Camera	720p HD Camera with Privacy Shutter
Dimensions	17.9mm
Connectivity	Wi-Fi 6, Bluetooth 5.1
Ports	HDMI 1.4b, Headphone / mic combo
