Lenovo G50-80 User Manual

34
G50-30/G50-45/G50-70/G50-70m/Z50-70/Z50-75/G50-80 Hardware Maintenance Manual
1020 Base cover
Foraccess,removethisFRU:
• “1010Batterypack”onpage33
Figure 2. Removal steps of base cover
Removethescrews
1
.Thenremovethebasecover
2
.




Step Screw (quantity) Color Torque
1
M2×3.5mm,Phillips-head,nylok-coated(3)
BigDoortoD
Black 1.5~2.0kgf*cm

Lenovo G50-80 Specifications

General

Weight	2.5 kg (5.51 lbs)
Webcam	720p HD webcam
Processor	Intel Core i3/i5/i7 (depending on model)
RAM	Up to 8GB DDR3L
Storage	Up to 1TB HDD
Display	15.6-inch HD (1366 x 768) or FHD (1920 x 1080)
Graphics	Intel HD Graphics or AMD Radeon R5 M330
Operating System	Windows 10
Battery	Up to 4 hours
Optical Drive	DVD-RW
Connectivity	Bluetooth 4.0
Ports	1 x USB 3.0, 2 x USB 2.0, HDMI, RJ-45, Audio Combo Jack
Card Reader	2-in-1 card reader (SD, MMC)
Dimensions	384 x 265 x 25 mm (15.1" x 10.4" x 0.98")
