G50-30/G50-45/G50-70/G50-70m/Z50-70/Z50-75/G50-80 Hardware Maintenance Manual
1100 ODD board and USB&audio board
Foraccess,removetheseFRUsinorder:
• “1010Batterypack”onpage33
• “1020Basecover”onpage34
• “1030Opticaldrive”onpage36
• “1040Harddiskdrive”onpage37
• “1050PCIExpressMiniCardforwirelessLAN”onpage39
• “1070Fanassembly”onpage42
• “1080Keyboard”onpage44
• “1090Keyboardbezel”onpage47
Figure 10. Removal steps of ODD board and USB&audio board
DetachtheODDboardconnectorinthedirectionsshownbyarrows
1
and
2
.
Removethescrew
3
.



Step Screw (quantity) Color Torque
3
M2×3.5mm,Phillips-head,nylok-coated(1)
ODDboard+D
Black 1.5~2.0kgf*cm
