Lenovo ThinkPad X1 Yoga Gen 8 User Manual

2. Insert the wireless WAN card into the slot at an angle of about 20 degrees 1 , and pivot downward 2 .
Install the screw to secure the wireless WAN card.
3 . Ensure you connect the blue cable to a
connector, the black with grey cable to b connector, the white cable to c connector, and the orange
cable to
d connector as shown 4 .
M.2 solid-state drive and bracket
Prerequisite
Before you start, read
Generic Safety and Compliance Notices and print the following instructions.
Attention: If you replace a M.2 solid-state drive, you might need to install a new operating system. For
details on how to install a new operating system, see “Install a Windows operating system and drivers” on
page 45.
The M.2 solid-state drive is sensitive. Inappropriate handling might cause damage and permanent loss of
data.
52
X1 Carbon Gen 11 and X1 Yoga Gen 8 User Guide

Lenovo ThinkPad X1 Yoga Gen 8 Specifications

General

Memory	Up to 32GB LPDDR5
Weight	Starting at 1.38 kg (3.04 lbs)
Operating System	Windows 11 Pro
Audio	Dolby Atmos Speaker System
Processor	13th Gen Intel Core i7
Display	14" 2.8K (2880 x 1800) OLED, 400 nits
Display Option	Touchscreen
Graphics	Intel Iris Xe Graphics
Storage	Up to 2TB PCIe SSD
Battery	57Wh
Ports	2x Thunderbolt 4, 2x USB-A 3.2 Gen 1, HDMI 2.1, headphone/mic combo jack
Connectivity	Wi-Fi 6E, Bluetooth 5.2
Camera	FHD 1080p with ThinkShutter
Security	Fingerprint reader, dTPM 2.0
