9.Positionthe3.5-inchharddiskdrivetogetherwiththebracketintotheserverandthenslidethedriveas
shownuntilthereleasepin
1snapsintoplace.
Figure64.Installingthe3.5-inchharddiskdrive
10.ConnecttheSATAcomboconnectortothe3.5-inchharddiskdrive.See“Connectingthecables”
onpage22.
11.Ifyouareinstructedtoreturntheoldharddiskdrive,followallpackaginginstructionsanduseany
packagingmaterialsthataresuppliedtoyouforshipping.
Whattodonext:
•Toworkwithanotherpieceofhardware,gototheappropriatesection.
•Tocompletethereplacement,goto“Completingthepartsreplacement”onpage106.
Replacingthefrontpanelboard
Attention:Donotopenyourserverorattemptanyrepairbeforereadingandunderstanding“Safetyinformation”
onpageiii
and“Guidelines”onpage53.
Note:ThisproceduremustbeperformedonlybytrainedservicepersonnelofLenovo.
Beforeyoubegin,printalltherelatedinstructionsorensurethatyoucanviewthePDFversiononanother
computerforreference.
Notes:
•ThefrontpanelboardissensitivetoESD.Ensurethatyoureadandunderstand“Handlingstatic-sensitive
devices”onpage54firstandcarefullyperformtheoperation.
•Dependingonthemodel,yourservermightlookslightlydifferentfromtheillustrationsinthistopic.
Toreplacethefrontpanelboard,dothefollowing:
1.Removeallmediafromthedrivesandturnoffallattacheddevicesandtheserver.Then,disconnectall
powercordsfromelectricaloutletsanddisconnectallcablesthatareconnectedtotheserver.
2.Iftheserverisinstalledinarackcabinet,removetheserverfromtherackcabinetandplaceitonaflat,
clean,andstatic-protectivesurface.
3.Removetheservercover.See“Removingtheservercover”onpage55.
4.Locatethefrontpanelboard.See“Servercomponents”onpage17.
90ThinkServerRS140UserGuideandHardwareMaintenanceManual
