FRUdescription
Self-service
CRU
Optional-service
CRU
ThinkServerRAID500UpgradeKeyforAdvancedRAID(availableonsome
models)
YesNo
ThinkServerRAID700Battery(availableonsomemodels)
YesNo
RAIDcard
SomeservermodelscomewithaRAIDcardinstalledinthelongerslotoftherisercardassemblytoprovide
advancedSATA/SAShardwareRAIDfunctions.YoualsocanpurchaseasupportedRAIDcardfromLenovo
andinstallitintotheserver.See“InstallingorremovingtheRAIDcard”onpage62
.
Note:TheoptionkitforaRAIDcardisdesignedfordifferenttypesofserversandmightcontainadditional
cablesthatarenotrequiredforyourserver.
YourserversupportsthefollowingRAIDcards:
•ThinkServerRAID500Adapter(alsoknownasThinkServer9240-8iRAID0/1Adapter)
•ThinkServerRAID700Adapter(alsoknownasThinkServer9260-8iSASRAIDAdapter)
ThinkServerRAID500Adapter(alsoknownasThinkServer9240-8iRAID0/1Adapter)
ThefollowingillustrationshowstheconnectorsontheThinkServerRAID500Adapter.
Figure11.ThinkServerRAID500Adapter
1Port02Port1
3TR500keyconnector
1Port0
Usedtoconnectamini-SASsignalcable.
2Port1
Usedtoconnectamini-SASsignalcable.
3TR500keyconnector
UsedtoconnectaThinkServerRAID500UpgradeKeyforAdvancedRAID.See“Installingorremovingthe
ThinkServerRAID500UpgradeKeyforAdvancedRAID”onpage66
.
Chapter3.Productoverview21
