Commissioning
5-1
BA2131EN
5 Commissioning
Stop!
l
Before switching on the mains voltage check the wiring for completeness, short circuit and
earth fault.
l
Keep to the switch-on sequence!
(Chapter 5.1 to chapter 5.2.2)
5.1 Configuration of the host system for communication with the
2131 fieldbus module.
TheLenzecontrollersarePROFIBUS-DPparticipantsin conformitywith standards.Communication
with the Simatic-S5 is possible, provided that the following Siemens hardware and software
components are available:
l
S5-interface module IM308-B or IM308-C
l
Programming software COM-ET200
The COM-ET200 software is available in a DOS version (COM-ET200 DOS) and in a Windows
version (COM-ET200 WIN). The following two sections explain the specific controller settings for
both versions. The third section gives a program example which is to support the commissioning.
5.1.1 Settings with COM-ET200 DOS
In the following, we describe how to configure a Lenze controller for the program package COM-ET
200 DOS:
1. Copy the file LE00AATD.200 from the diskette to the COM-ET200 directory.
2. Fill in the boxes of the menus indicated then:
Menu: ET200 system parameter
Bus profile: DP standard
Menu: Configure
Station type: Lenze 2131 Vxx
Configuration: User data with DP parameter-setting channel
0. = 115; 1. = 113 oder
0. = 115; 1. = 114
User data without DP parameter-setting channel
0. = 113 or
0. = 114
5.1.2 Settings with COM-ET200 WIN
In the following we describe how to configure a Lenze controller for the program package
COM-ET200 WIN:
1. Copy the file LE00AAAX.200 from the diskette to the COM-ET200 directory.
2. Select the 2131 fieldbus module via the slave family DRIVES.
