9 Troubleshooting and fault elimination
Possible cause of error Diagnostics Remedy
The device is not switched on Power LED does not illuminate Check external voltage supply
CAN bus error ERR LED is lit or blinking Check CAN wiring
9.1 Signalling of the CANopen RUN LED and ERROR LED
9.1.1 CAN operating mode
CANopen ERROR LED
The CANopen ERROR LED displays the status of the physical CAN level and shows errors on
the basis of missing CAN messages (SYNC, GUARD or HEARTBEAT). It is lit red.
No. ERROR LED STATUS Description
1 OFF No error The device is ready for operation.
2 Single lighting
up
Warning limit is
reached
At least one of the error counters of the CAN controller has
reached or exceeded the warning level (too many error
frames).
3 Flicker AutoBaud/LSS The automatic baud rate detection or LSS services are
running. (ERROR LED and RUN LED flicker alternately).
4 Double lighting
up
Error control event A guard event (NMT slave or NMT master) or heartbeat
event (heartbeat consumer) has occurred.
5 Triple lighting
up
Sync error The sync message has not been received within the time
configured for the time monitoring of the communication
cycle..
6 On Bus Off The CAN controller is in the bus−off state.
CANopen RUN LED
The CANopen RUN LED displays the CANopen−NMT status. It is lit up green.
No. CAN RUN LED STATUS Description
1 Flicker AutoBaud/LSS The automatic baud rate detection or LSS services are
running. (ERROR LED and RUN LED flicker alternately).
Optional
2 Single lighting
up
STOPPED The device in the STOPPED state.
3 Blinking PRE−OPERATIONAL The device is in the PREOPERATIONAL state.
4 On OPERATIONAL The device is in the OPERATIONAL state.
Message states and lighting rates
The following message states are distinguished:
