Montage Extension Board (Option)
S
EDK10200EV3 DE/EN/FR 5.0
ON
L
Abb. 1-10
PES
PES
1
4
A
B
C
C
2
3
plc015
1. Schutzkappe entfernen und aufbewahren.
2. Stiftleisten auf das Extension Board einsetzen.
3. Extension Board in die Drive PLC einsetzen.
4. Verdrahtung: siehe Montageanleitung des Extension Board.
