Control connections
P
EDK10200EV3 DE/EN/FR 5.0
PV
L
Terminal strips on the top of the instrument
z The Drive PLC can only be connected to a supply voltage of max. +30 V DC !
z Higher voltages, or AC, will destroy the instrument !
plc002
X3 I8
I4 I7
I3 I6
I2
I5
I1
3K
3K
3K
3K
3K
3K
3K
3K
X2 O1 O2 O3 O4
+
~~
-
X1 +O24
+24
24
Z Z Z Z
Abb. 1-18
Connection required Possible connection
c
Encoder
d
Load
e
Emergency off
f
External DC supply voltage
g
Supply for control electronics
