Extension Board mounting (option)
S
EDK10200EV3 DE/EN/FR 5.0
QR
L
Abb. 1-22
PES
PES
1
4
A
B
C
C
2
3
plc015
1. Remove and store the protective cover .
2. Insert the pin connector strips on the Extension Board .
3. Insert the Extension Board into the Drive PLC.
4. Wiring: See Mounting Instructions for the Extension Board.
