Operation
Calling up information messages
6
81
EDBPM−H505 DE/EN/FR 6.1
6.3 Calling up information messages
ƒ Information messages
– are texts which appear because of a certain event (e.g. if an actual value
exceeds a limit),
– can only be called up as long as the triggering event is active.
– must have been programmed in the planning tool »HMI Designer«.
– can have a length of up to 5 lines of 30 characters (single character
size).
ƒ The second to last line contains a programmable message field. This field
indicates the numerical size of the variable that has activated the
message.
ƒ The last line shows the date and time when the message was initiated.
ƒ signals when an information message is present.
Symbols and characters in the information messages
Symbols/characters on the date/time line Meaning
* The information message was called for the first
time
HELP Help is assigned to the information message. ( 84)
If you want to ... Touch the fields... Example
A ... call up an information message.
ESC
Temperature exceeds
safety limit
1700
13-09-2000 10:55a HELP
125.5
13-09-2000 10:45a HELP
Pressure exceeds
safety limit
B
... select the next information
messages.
or
ESC
Water level below
working threshold
-10
13-09-2000 11:00a HELP
C ... close the information messages.
ESC
