Lenze EPM-H505 User Manual

Operation
Calling up alarm messages
6

83
EDBPM−H505 DE/EN/FR 6.1
If you want to ... Touch the fields... Example
A ... call up an alarm message.
0006
0001
0032
ESC
HIST
Pressure exceeds
safety limit
125.5
>13-09-2000 10:45a HELP
Temperature exceeds
safety limit
1600
>13-09-2000 10:55a
<13-09-2000 10:58a HELP
Water level below
working threshold
-10
>13-09-2000 11:00a
#13-09-2000 11:05a HELP
B ... select the alarm register for an
alarm message.
l The alarm register logs all
alarms chronologically, with
time and date stamping.
l If H" is in the left column, the
alarm register has been
selected.
HIST
0006
0032
0001
H
H
H
ESC
Pressure exceeds
safety limit
125.5
>13-09-2000 10:45a
<13-09-2000 10:48a
Temperature exceeds
safety limit
1600
>13-09-2000 10:55a
<13-09-2000 10:58a
Water level below
working threshold
-10
>13-09-2000 11:00a
#13-09-2000 11:05a
l Close the alarm register and go
back to the alarm message.
ESC
C ... close the alarm messages.
ESC
 Note!
ƒ If the alarm register buffer is full, no more alarms are saved.
ƒ Use the »HMI Designer« to define command for acknowledging
alarms or deleting them from the alarm register.
