3 Product description
Stop!
The MOC geared motors GKK are classified as light load or heavy load;
see the characteristics in the following tables .
• The most important technical data is given on the nameplate.
• The product catalogues contain further technical data.
3.1 Identification
3.1.1 mêçÇìÅí ÑÉ~íìêÉë
Design
Drive systems have a modular design.
They consist of:
• Speed reduction gearbox
– Bevel gearbox in different ratios with integrated clutch
• Electric motor
– Three-phase AC motor
Mode of operation
• Torque and speed conversion
Product family 1st stage 2nd stage
Bevel gearbox Helical Bevel
Note!
The reaction torque must be supported by foot mounting, flange
mounting, or torque plate.
•Clutch
Jaw coupling between 1st and 2nd gearbox stage that is activated from the outside by
means of an operating lever.
