Lenze G Series User Manual

Technical data
Important notes
4
20
Lenze • BA 12.0032 • 4.0
4 Technical data
4.1 Important notes
• The most important technical data are indicated on the nameplate (structure and
contents  16).
• The product catalogues contain further technical data.
The output torque and radial forces are rated data and dependent upon:
• Speed
• Mounting position
• Ambient temperature
•Ratio
• Motor power
• Application of force of radial load
Depending on the application, the permissible load can be reduced.
4.2 Characteristics for light load application
Gearbox
type
Max. torque Max. radial force Driven
shafts
Ratios
Speed variants
[Nm] [N] dxl[mm] [i]
GKK
04-2M...
70 5600 20 x 35
7.72
15.16
19.52
40.84
FU
GKK
05-2M...
160 8000 25 x 35
12.38
19.74
24.56
38.57
FU
4.3 Characteristics for heavy load application
Gearbox
type
Max. torque Max. radial force Driven
shafts
Ratios
Speed variants
[Nm] [N] dxl[mm] [i]
GKK
05-2M...
200 10000 25 x 35
12.38
19.74
24.56
38.57
FU
GKK
06-2M...
500 20000 35 x 70
17.50
27.90
34.71
54.51
FU
GKK
07-2M...
900
25000 45 x 90
15.43
27.00
43.07
86.79
FU
GKK
07-2M...
36000 55 x 110 FU
