Product description
Gearbox code
3
18
Lenze ¯ MA 12.0014 ¯ 5.1
3.2.2 Gearbox code
Example G 50 A B 045 M H B R 2 N 2E
Meaning Variant Gearbox code
Product family G 50
Generation A
B
Gearbox type Bevel gearbox B
Output torque 45 Nm 045
110 Nm 111
240 Nm 124
450 Nm 145
600 Nm 160
820 Nm 182
1500 Nm 215
2700 Nm 227
4300 Nm 243
8000 Nm 280
13000 Nm 313
20000 Nm 320
Type of construction Geared motor M
Gearbox N
Shaft type Solid shaft with featherkey V
Hollow shaft with keyway H
Hollow shaft with shrink disk S
Housing type Foot mounting + centering A
Foot mounting B
Centering C
Flange mounting Without flange R
Flange with through holes K
Number of stages 2−stage 2
3−stage 3
Drive size Without adapter (integrated motor) C
00
...
82
1A
...
2K
NEMA adapter with a jaw coupling
with a keyway
A
NEMA adapter with a plug−in hollow
shaft with a keyway
B
IEC adapter with a plug−in hollow shaft
with a keyway
H
IEC adapter with a jaw coupling N
IEC adapter with a jaw coupling with a
keyway
T
