About this documentation
Document history
1
6
Lenze ¯ MA 12.0014 ¯ 5.1
1.1 Document history
Material number Version Description
13457390 1.0 02/2014 TD29 First edition for the pilot series
.Xqô 5.1 09/2018 TD29 "Maintenance" chapter: g500−B240 − lubricated for
life
Table new: load carrying capacity of the eye bolt
.Xqô 5.1 09/2018 TD29 Complete revision including the cast iron gearboxes
13535365 4.0 05/2017 TD09 Drawing exchanged in the chapter "Disassembly of
gearbox with hollow shaft"
Auxiliary tool table supplemented
Important note corrected in the Maintenance
chapter
Ambient temperatures changed in the lubricant
table
13553160
5.0 06/2018 TD15 Array of products extended
.Xqô 5.1 09/2018 TD29 Error corrections
1.2 Conventions used
This documentation uses the following conventions to distinguish different types of
information:
Type of information Writing Example/notes
Numeric notation
Decimal Standard notation Example: 1234
Decimal separator Point The decimal point is always used.
For example: 1234.56
Icons
Page reference
^
Reference to another page with additional
information
For instance:
^ 16 = see page 16
Documentation reference
,
Reference to another documentation with
additional information
Example:
, EDKxxx = see EDKxxx documentation
Wildcard
L
Wildcard for options, selection data
1.3 Terminology used
Term In the following text used for
Gearboxes Gearboxes of the g500 product family
Drive system Drive systems with g500 gearboxes and other Lenze drive
components
