Operating instructions i550 motec frequency inverter | 2
© 03/2022 · EN · www.Lenze.com
General information
Identication
Information
Overview
Hardware overview of the inverter
M23 power
Status LEDs
Han Q8
X100.2
X397
X1
X100.1
X105
X3.1
X3.2
X16
X396
M25
Warnings
Functional
safety
(Basic Safety - STO)
Fan, option
Wall adapter, option
Power supply
Motor connection
Nameplate
Network (OUT)
Network (IN)
Control connections
Control connections
Diagnostic interface
Power supply
option
Han Q4/2 female
Han Q4/2 male
(Daisy Chain)
