Operating instructions i550 motec frequency inverter | 32
© 03/2022 · EN · www.Lenze.com
Error code Description Classication Remedy Blocking time [s]
2250 CiA: Continuous overcurrent (inside the device) Error
• Check motor and wiring for short circuits.
• Check brake resistor and wiring.
• Check motor circuit (delta connection, star connection).
• Check setting of the motor data.
5
2320 Short circuit or earth leakage on motor side Error
• Check motor cable.
• Check the length of the motor cable.
• Use shorter or lower-capacitance motor cable.
5
2340 CiA: Short circuit (inside the device) Error • Check motor cable for short circuit. 5
2350 CiA: i²*t overload (thermal state) Error
• Check drive sizing.
• Check machine/driven mechanics for excessive load.
• Check setting of the motor data.
• Reduce values for slip compensation (0x2B09:001, 0x2B09:002) and oscillation damping (0x2B0A:001,
0x2B0A:002).
5
2382 Error - device utilization (Ixt) too high Error
• Check drive sizing.
• Reduce maximum overload current of the inverter (0x6073).
• In case of high mass inertias, reduce maximum overload current of the inverter (0x6073) to 150%.
3
2383 Warning - device utilization (Ixt) too high Warning • Check drive sizing. 0
3120 Mains phase fault Error
• Check mains connection wiring.
• Check fuses.
0
3210 Error - DC bus overvoltage Error
• Reduce dynamic performance of the load prole.
• Check mains voltage.
• Check settings for the brake energy management.
0
3211 Warning: DC-bus overvoltage Warning 0
3220 Error - DC-bus undervoltage Trouble
• Check mains voltage.
• Check fuses.
• Check DC-bus voltage (0x2D87).
• Check mains settings.
0
3221 Warning: DC bus undervoltage Warning 0
3222 DC-bus voltage too low for switch-on Warning
• Check mains voltage.
• Check fuses.
• Check mains settings.
0
4210 Error - power section overtemperature Error
• Check mains voltage.
• Ensure sucient cooling of the device (display of heatsink temperature in 0x2D84:001).
• Clean fan and ventilation slots. If required, replace fan.
• Reduce switching frequency (0x2939).
0
4281 Warning - heatsink fan Warning
• Clean fan and ventilation slots. If required, replace fan. The fans can be unlocked via locking hooks and can
then be removed.
0
4310 Motor overtemperature Error
• Check drive sizing.
• Check motor temperature sensor and wiring at X105/T1+T2 or X109/T1+T2.
5
5112 24 V supply critical Warning
• Check optional external auxiliary supply on X100.1/24E.1, if connected.
• Check mains voltage.
0
5180 24 V supply overload Warning • Check 24 V output and digital outputs for earth fault or overload. 0
Error codes
Troubleshooting
Error codes
LED statusError message
