Operating instructions i550 motec frequency inverter | 4
© 03/2022 · EN · www.Lenze.com
Identication of the products
General information
Identication
Information
Overview Conventions
1
Rated power
[kW]
137 0.37
155 0.55
175 0.75
211 1.1
215 1.5
222 2.2
230 3
240 4
255 5.5
2
Mains voltage and connection type
C
3/PE AC 230/240 V
F
3/PE AC 400 V
3/PE AC 480 V
3
Product variant
0
Without control elements
A
With repair switch
B
With repair switch, monitored
C
With repair switch with protective function
D
With repair switch with protective func-
tion, monitored
E
With repair switch, monitored, and control
elements
F
With repair switch, monitored, control
element, and potentiometer
G
With repair switch and control elements
H
With repair switch, control element, and
potentiometer
I
With repair switch with protective func-
tion, and control elements
J
With repair switch with protective func-
tion, monitored, and control elements
K
With repair switch with protective func-
tion, control element, and potentiometer
L
With repair switch with protective func-
tion, monitored, control element, and
potentiometer
4
Integrated functional safety
0
Without safety function
A
Basic Safety - STO
5
Design/mounting
0
Without adapter
A
Wall adapter with Han Q8
B
Wall adapter with cable gland (M25)
C
Wall adapter with M23 power
D
Wall adapter with Han Q8 and fan
E
Wall adapter with cable gland (M25) and
fan
F
Wall adapter with M23 power and fan
G
Wall adapter with cable gland (M40)
H
Wall adapter with M40 power
I
Motor adapter for BG063 - BG071
J
Motor adapter for BG080 - BG112
K
Motor adapter for BG132
L
Motor adapter for BG160 - BG180
6
Application area
0
Default parameter setting: Region EU (50-
Hz networks)
1
Default parameter setting: Region US (60-
Hz networks)
7
WLAN
0
Without WLAN
W
With WLAN
8
Control connections
0
Standard I/O
1
Application I/O
9
Network
K
EtherCAT
L
PROFINET
M
EtherNet/IP
W
Modbus TCP
5 5 A M 137 FI 0 A D 0 0 0
1 2 3 4 5 6 7
0 K
8 9
S
