Assignment of the terminal boxes
Assignment of the terminal boxes with one temperature monitor
Motor MF☐MA☐☐
063-32 071-32 080-32 090-32 100-12 112-22 132-12
063-42 071-42 080-42 100-32 132-22
132-32
Without product extensions
Terminal box KK1 KK1 KK1 KK1 KK1 KK1 KK1
ICN connector
Power ICN-M23 ICN-M23 ICN-M23 ICN-M23 ICN-M23 - -
Terminal box KK1 KK1 KK1 KK1 KK1 - -
Product extension - brake
Terminal box KK2 KK2 KK2 KK2 KK2 KK2 KK3
ICN connector
Power/brake ICN-M23 ICN-M23 ICN-M23 ICN-M23 ICN-M23 - -
Terminal box KK2 KK2 KK2 KK2 KK2 - -
Product extension - feedback
Terminal box KK2 KK2 KK2 KK2 KK2 KK2 KK3
ICN connector
Power/brake ICN-M23 ICN-M23 ICN-M23 ICN-M23 ICN-M23 - -
Feedback ICN-M23 ICN-M23 ICN-M23 ICN-M23 ICN-M23 - -
Terminal box KK2 KK2 KK2 KK2 KK2 - -
Product extension - brake +
feedback
Terminal box KK3 KK3 KK3 KK3 KK3 KK3 KK3
ICN connector
Power/brake ICN-M23 ICN-M23 ICN-M23 ICN-M23 ICN-M23 - -
Feedback ICN-M23 ICN-M23 ICN-M23 ICN-M23 ICN-M23 ICN-M23 ICN-M23
Terminal box KK2 KK2 KK2 KK2 KK2 KK2 KK3
Product extension - blower
Terminal box ● ● ● ● ● ● ●
Power connector ICN-M17 ICN-M17 ICN-M17 ICN-M17 ICN-M17 ICN-M17 ICN-M17
Assignment of the terminal boxes with two temperature monitors
Motor MF☐MA☐☐
063-32 071-32 080-32 090-32 100-12 112-22 132-12
063-42 071-42 080-42 100-32 132-22
132-32
Without product extensions
Terminal box KK2 KK2 KK2 KK2 KK2 KK2 KK3
Product extension - brake
Terminal box KK2 KK2 KK2 KK2 KK2 KK2 KK3
Product extension - feedback
Terminal box KK2 KK2 KK2 KK2 KK2 KK2 KK3
Product extension - brake +
feedback
Terminal box KK3 KK3 KK3 KK3 KK3 KK3 KK3
Product extensions
Motor connecon
Assignment of the terminal boxes
122
