Lenze IE2 g500-H User Manual

g500-H100, 3-stage gearboxes
Max. output torque Rao Number of teeth Max. backlash
Standard
M
2, max
i z
g
z
t
Nm '
100 59.505 6248 105 22
100 83.307 6248 75 22
100 106.259 15620 147 22
100 130.167 781 6 22
100 163.638 17182 105 21
100 198.597 69509 350 21
100 255.769 107423 420 21
100 324.156 499201 1540 21
100 406.221 56871 140 21
100 519.188 8307 16 21
g500-H140, 2-stage gearboxes
Max. output torque Rao Number of teeth Max. backlash
Standard
M
2, max
i z
g
z
t
Nm '
63.0 2.053 75 154 27
83.0 2.912 125 364 26
38.6 3.267 49 15 25
52.9 4.480 112 25 24
63.3 5.733 86 15 23
34.1 6.272 784 125 23
40.4 8.000 8 1 23
107 9.029 316 35 18
89.1 9.800 49 5 23
128 11.554 3397 294 18
68.8 12.640 316 25 18
81.5 16.122 790 49 18
140 19.750 79 4 18
106 24.829 869 35 18
115 31.976 1343 42 18
127 40.526 6241 154 17
129 50.786 711 14 17
88.9 66.908 6557 98 17
Technical data
Data overview
41
