Lenze SMD Series Reference Guide

19 RG-SDMOD
Drive Control & Communication
6 smd Programming Parameters
6.1 Format
NOTE - Attention
Parameter list presented in Section 6.2 is valid only for smd parameter version 400 and
507. For revisions, refer to appropriate smd Manual.
Abbreviations:
SA (1byte) Drive Address (1-247)
RA (1byte) Register Address
CRCH Cyclic Redundancy Check High byte
CRCL Cyclic Redundancy Check Low byte
READING:
Message structure for reading 1 word: (most of parameters)
Request: SA 03 00 RA 00 01 CRCH CRCL
Response: SA 03 02 DH DL CRCH CRCL
Message structure for reading 4 word: (Parameter C99 Software Version)
Request: SA 03 00 RA 00 04 CRCH CRCL
Response: SA 03 08 D1H D1L D2H D2L D3H D3L D4H D4L CRCH CRCL
WRITING:
Message structure for writing 1 word: (all parameters)
Request: SA 06 00 RA DH DL CRCH CRCL
Response: SA 06 00 RA DH DL CRCH CRCL
LEGEND for Parameter List
1st Column: Parameter No.
1
= Drive's programming code number
4th Column: Range of Adjustment
2
= Selections in bold are for smd models with PV507 only.
Phone: 800.894.0412 - Fax: 888.723.4773 - Web: www.clrwtr.com - Email: info@clrwtr.com

Lenze SMD Series Specifications

General

Output Voltage	0 to Input Voltage
Protection Class	IP20
Overload Capacity	150% for 60 seconds
Braking Resistor	Optional
Control Method	V/f control
Communication	CANopen
Protection Features	Overvoltage, Undervoltage, Overcurrent, Overtemperature
Power Range	0.25 kW to 22 kW
Ambient Temperature	-10°C to +50°C (without derating)
