Lenze SMD Series Reference Guide

RG-SDMOD 20
Drive Control & Communication
6.2 Parameter List
Parameter No.
1
smd Register #
(hexadecimal
representation)
Parameter Name Range of Adjustment
2,
Modbus value (decimal value)
Factory
Default
PV400 PV507
C01 51 (33H) 51 (33H) Setpoint and Control
Source
Speed Control Program
0 Analog Terminal Keypad
1 c40 Terminal Keypad
2 Analog Terminal LECOM
3 LECOM LECOM LECOM
4 Analog Terminal Remote Keypad
5 c40 Terminal Remote Keypad
6 Analog Remote Keypad Remote Keypad
7 c40 Remote Keypad Remote Keypad
8 Analog Terminal Modbus
9 c40 Terminal Modbus
10 Analog Modbus Modbus
11 c40 Modbus Modbus
0
C02 52 (34H) 52 (34H) Load Lenze setting 0 No action/loading complete
1 Load 50Hz Defaults
2 Load 60Hz Defaults
3 Load OEM Defaults
4 Translate compatible EPM
NOTE: Drive must be in OFF or Inhibit state to change
0
CE1
CE2
CE3
53 (35H)
54 (36H)
55 (37H)
53 (35H)
54 (36H)
55 (37H
Configuration
Digital Inputs
E1, E2, E3
1 Activate fixed setpoint 1 (JOG1)
2 Activate fixed setpoint 2 (JOG2)
3 DC Braking (DCB)
4 Direction of Rotation
5 Quick Stop
6 CW Rotation
7 CCW Rotation
8 UP
9 DOWN
10 TRIP set
11 TRIP reset
12 Accel/decel 2
13 Deactivate PI
14 Activate fixed PI setpoint 1
15 Activate fixed PI setpoint 2
CE1 = 1
CE2 = 4
CE3 = 3
1 = The drive's programming code number; 2 = Selections in bold are for
smd models with PV507 only.
Phone: 800.894.0412 - Fax: 888.723.4773 - Web: www.clrwtr.com - Email: info@clrwtr.com

Lenze SMD Series Specifications

General

Output Voltage	0 to Input Voltage
Protection Class	IP20
Overload Capacity	150% for 60 seconds
Braking Resistor	Optional
Control Method	V/f control
Communication	CANopen
Protection Features	Overvoltage, Undervoltage, Overcurrent, Overtemperature
Power Range	0.25 kW to 22 kW
Ambient Temperature	-10°C to +50°C (without derating)
