This documentation applies to the optional Additional I/O module for the SMVector inverter and should be used
in conjunction with the SMVector Operating Instructions (Document SV01) that shipped with the drive. These
documents should be read in their entirety as they contain important technical data and describe the installation
and operation of the drive.
NOTE
To use the I/O Module with SMVector drives rated at 0.33 to 10 HP (0.25 to 7.5 kW) requires
that the drive has software version 3.0 or higher. The software version can be found in
the SMVector drive diagnostic parameter P501. To use the I/O Module options the value
displayed in P501 must be 3.00 or higher.
SMVector drives rated at 15 HP (11.0 kW) and higher all support the I/O options models so
there is no need to verify the value in P501.
©2008 Lenze Americas Corporation
No part of this documentation may be copied or made available to third parties without the explicit written approval of Lenze
Americas Corporation. All information given in this documentation has been carefully selected and tested for compliance with
the hardware and software described. Nevertheless, discrepancies cannot be ruled out. Lenze Americas does not accept any
responsibility nor liability for damages that may occur. Any necessary corrections will be implemented in subsequent editions.
SMVector I/O Module ALSV01 v1.0 13376253 3
Contents
1 Safety Information .............................................................................................................5
1.1 Warnings, Cautions and Notes ..............................................................................5
1.1.1 General ....................................................................................................5
1.1.2 Application ...............................................................................................5
1.1.3 Installation ...............................................................................................5
1.1.4 Electrical Connection ................................................................................6
1.1.5 Operation .................................................................................................6
2 Introduction .......................................................................................................................7
2.1 Module Overview ..................................................................................................7
2.2 Module Specifi cation ............................................................................................7
2.3 Module Identifi cation Label ...................................................................................7
3 Installation ........................................................................................................................8
3.1 Mechanical Installation .........................................................................................8
3.2 Module Terminal Block .........................................................................................9
3.3 Electrical Installation .............................................................................................10
3.3.1 Terminal Description ................................................................................10
3.3.2 Module Wiring ..........................................................................................10
4 Commissioning .................................................................................................................11
4.1 Network Parameters (P400) ..................................................................................11
4.2 Additional I/O Module Parameters .........................................................................12
4.3 Display .................................................................................................................14
