Lexicon MC-1 Service Manual

Lexicon
4-9
Lexicon Audio Precision ATE Summary
This chart represents a summary of test Audio Precision test equipment settings and parameters used by
Lexicon Manufacturing in production testing of all MC-1 product. This is provided as a reference and
supplement to bench test settings found in the proof of performance in this manual.
All Tests = 25 Ohm, Unbal, Float
All Tests = Filter OFF, Imp. 100K, 44.1kHz Sample Rate (Except 48K Tests)
Typical Remote
Test Name Left Right Freq (Hz) Level Measure Reading Upper Lower Band Commands
DIGGAN44 -1dBFS -1dBFS 997 Vrms AMPLITUDE 7.1 7.66 6.54 <10>500K COAX1#1 ShiftCD DOLBY
DIG997 -1dBFS -1dBFS 997 % THD+N 0.003 0.005 0.0002 <10-22K COAX1#1 ShiftCD DOLBY
DIG100 -1dBFS -1dBFS 100 % THD+N 0.003 0.005 0.0002 <10>500K COAX1#1 ShiftCD DOLBY
JITTER44 -1dBFS -1dBFS 10,000 % THD+N 0.003 0.008 0.0002 <10-22K COAX1#1 ShiftCD DOLBY
DIGD_R -60dBFS -60dBFS 997 dBr AMPLITUDE -103 -99.94 -120 <10-22K COAX1#1 ShiftCD DOLBY
DIGFREQ -1dBFS -1dBFS 10-20K dBr AMPLITUDE 0 0.26 -0.36 <10-22K COAX1#1 ShiftCD DOLBY
DIGGAN44 -1dBFS -1dBFS 997 Vrms AMPLITUDE 7.1 7.66 6.54 <10>500K COAX2#1 ShiftCD THX
DIG997 -1dBFS -1dBFS 997 % THD+N 0.003 0.005 0.0002 <10-22K COAX2#1 ShiftCD THX
DIG100 -1dBFS -1dBFS 100 % THD+N 0.003 0.005 0.0002 <10>500K COAX2#1 ShiftCD THX
JITTER44 -1dBFS -1dBFS 10,000 % THD+N 0.003 0.008 0.0002 <10-22K COAX2#1 ShiftCD THX
DIGD_R -60dBFS -60dBFS 997 dBr AMPLITUDE -103 -99.94 -120 <10-22K COAX2#1 ShiftCD THX
DIGFREQ -1dBFS -1dBFS 10-20K dBr AMPLITUDE 0 0.26 -0.36 <10-22K COAX2#1 ShiftCD THX
DIGGAN44 -1dBFS -1dBFS 997 Vrms AMPLITUDE 7.1 7.66 6.54 <10>500K COAX3#1 ShiftCD L7
DIG997 -1dBFS -1dBFS 997 % THD+N 0.003 0.005 0.0002 <10-22K COAX3#1 ShiftCD L7
DIG100 -1dBFS -1dBFS 100 % THD+N 0.003 0.005 0.0002 <10>500K COAX3#1 ShiftCD L7
JITTER44 -1dBFS -1dBFS 10,000 % THD+N 0.003 0.008 0.0002 <10-22K COAX3#1 ShiftCD L7
DIGD_R -60dBFS -60dBFS 997 dBr AMPLITUDE -103 -99.94 -120 <10-22K COAX3#1 ShiftCD L7
DIGFREQ -1dBFS -1dBFS 10-20K dBr AMPLITUDE 0 0.26 -0.36 <10-22K COAX3#1 ShiftCD L7
DIGGAN44 -1dBFS -1dBFS 997 Vrms AMPLITUDE 7.1 7.66 6.54 <10>500K COAX4#1 ShiftCD DTS
DIG997 -1dBFS -1dBFS 997 % THD+N 0.003 0.005 0.0002 <10-22K COAX4#1 ShiftCD DTS
DIG100 -1dBFS -1dBFS 100 % THD+N 0.003 0.005 0.0002 <10>500K COAX4#1 ShiftCD DTS
JITTER44 -1dBFS -1dBFS 10,000 % THD+N 0.003 0.008 0.0002 <10-22K COAX4#1 ShiftCD DTS
DIGD_R -60dBFS -60dBFS 997 dBr AMPLITUDE -103 -99.94 -120 <10-22K COAX4#1 ShiftCD DTS
DIGFREQ -1dBFS -1dBFS 10-20K dBr AMPLITUDE 0 0.26 -0.36 <10-22K COAX4#1 ShiftCD DTS
DIGGAN44 -1dBFS -1dBFS 997 Vrms AMPLITUDE 7.1 7.66 6.54 <10>500K COAX5#1 ShiftCD 2 CH
DIG997 -1dBFS -1dBFS 997 % THD+N 0.003 0.005 0.0002 <10-22K COAX5#1 ShiftCD 2 CH
DIG100 -1dBFS -1dBFS 100 % THD+N 0.003 0.005 0.0002 <10>500K COAX5#1 ShiftCD 2 CH
JITTER44 -1dBFS -1dBFS 10,000 % THD+N 0.003 0.008 0.0002 <10-22K COAX5#1 ShiftCD 2 CH
DIGD_R -60dBFS -60dBFS 997 dBr AMPLITUDE -103 -99.94 -120 <10-22K COAX5#1 ShiftCD 2 CH
DIGFREQ -1dBFS -1dBFS 10-20K dBr AMPLITUDE 0 0.26 -0.36 <10-22K COAX5#1 ShiftCD 2 CH
DIGGAN44 -1dBFS -1dBFS 997 Vrms AMPLITUDE 7.1 7.66 6.54 <10>500K OPTIC1#1 ShiftCD PARTY
DIG997 -1dBFS -1dBFS 997 % THD+N 0.003 0.005 0.0002 <10-22K OPTIC1#1 ShiftCD PARTY
DIG100 -1dBFS -1dBFS 100 % THD+N 0.003 0.005 0.0002 <10>500K OPTIC1#1 ShiftCD PARTY
JITTER44 -1dBFS -1dBFS 10,000 % THD+N 0.003 0.008 0.0002 <10-22K OPTIC1#1 ShiftCD PARTY
DIGD_R -60dBFS -60dBFS 997 dBr AMPLITUDE -103 -99.94 -120 <10-22K OPTIC1#1 ShiftCD PARTY
DIGFREQ -1dBFS -1dBFS 10-20K dBr AMPLITUDE 0 0.26 -0.36 <10-22K OPTIC1#1 ShiftCD PARTY
DIGGAN44 -1dBFS -1dBFS 997 Vrms AMPLITUDE 7.1 7.66 6.54 <10>500K OPTIC2#1 ShiftCD TVM
DIG997 -1dBFS -1dBFS 997 % THD+N 0.003 0.005 0.0002 <10-22K OPTIC2#1 ShiftCD TVM
DIG100 -1dBFS -1dBFS 100 % THD+N 0.003 0.005 0.0002 <10>500K OPTIC2#1 ShiftCD TVM
JITTER44 -1dBFS -1dBFS 10,000 % THD+N 0.003 0.008 0.0002 <10-22K OPTIC2#1 ShiftCD TVM
DIGD_R -60dBFS -60dBFS 997 dBr AMPLITUDE -103 -99.94 -120 <10-22K OPTIC2#1 ShiftCD TVM
DIGFREQ -1dBFS -1dBFS 10-20K dBr AMPLITUDE 0 0.26 -0.44 <10-22K OPTIC2#1 ShiftCD TVM
DIGGAN44 -1dBFS -1dBFS 997 Vrms AMPLITUDE 7.1 7.66 6.54 <10>500K OPTIC3#1 ShiftCD MUSIC
DIG997 -1dBFS -1dBFS 997 % THD+N 0.003 0.005 0.0002 <10-22K OPTIC3#1 ShiftCD MUSIC
DIG100 -1dBFS -1dBFS 100 % THD+N 0.003 0.005 0.0002 <10>500K OPTIC2#1 ShiftCD MUSIC
JITTER44 -1dBFS -1dBFS 10,000 % THD+N 0.003 0.008 0.0002 <10-22K OPTIC3#1 ShiftCD MUSIC
DIGD_R -60dBFS -60dBFS 997 dBr AMPLITUDE -103 -99.94 -120 <10-22K OPTIC3#1 ShiftCD MUSIC
DIGFREQ -1dBFS -1dBFS 10-20K dBr AMPLITUDE 0 0.26 -0.44 <10-22K OPTIC3#1 ShiftCD MUSIC
DIGREC -1dBFS -1dBFS 997 Vrms AMPLITUDE 2Vrms 2.3 1.69 <10-22K COAX1#1 ShiftCD DOLBY
CLKRNG44 -1dBFS -1dBFS 997 % THD+N 0.003 0.008 0.002 <10-22K COAX1#1 ShiftCD DOLBY
NOTE: GAIN 48, JITTER 48, AND CLKRNG48 use a 48kHz Sample
Rate
DIGGAN48 -1dBFS -1dBFS 997 Vrms AMPLITUDE 7.1 7.66 6.54 <10>500K COAX1#1 ShiftAUX DOLBY
JITTER48 -1dBFS -1dBFS 10,000 % THD+N 0.003 0.008 0.0002 <10-22K COAX1#1 ShiftAUX DOLBY
DIGGAN48 -1dBFS -1dBFS 997 Vrms AMPLITUDE 7.1 7.66 6.54 <10>500K COAX2#1 ShiftAUX THX
JITTER48 -1dBFS -1dBFS 10,000 % THD+N 0.003 0.008 0.0002 <10-22K COAX2#1 ShiftAUX THX
DIGGAN48 -1dBFS -1dBFS 997 Vrms AMPLITUDE 7.1 7.66 6.54 <10>500K COAX3#1 ShiftAUX L7
JITTER48 -1dBFS -1dBFS 10,000 % THD+N 0.003 0.008 0.0002 <10-22K COAX3#1 ShiftAUX L7
DIGGAN48 -1dBFS -1dBFS 997 Vrms AMPLITUDE 7.1 7.66 6.54 <10>500K COAX4#1 ShiftAUX DTS
JITTER48 -1dBFS -1dBFS 10,000 % THD+N 0.003 0.008 0.0002 <10-22K COAX4#1 ShiftAUX DTS
DIGGAN48 -1dBFS -1dBFS 997 Vrms AMPLITUDE 7.1 7.66 6.54 <10>500K COAX5#1 ShiftAUX 2 CH
JITTER48 -1dBFS -1dBFS 10,000 % THD+N 0.003 0.008 0.0002 <10-22K COAX5#1 ShiftAUX 2 CH
DIGGAN48 -1dBFS -1dBFS 997 Vrms AMPLITUDE 7.1 7.66 6.54 <10>500K OPTIC1#1 ShiftAUX PARTY
