LG 19LD310 User Manual

12
PREPARATION
PREPARATION
HDMI IN HDMI/DVI IN
1
1
2
2
RGB IN
COMPONENT IN
AUDIO
ANTENNA
IN
AV
VIDEO
VARIABLE
AUDIO OUT
ANTENNA CONNECTION
■
For optimum picture quality, adjust antenna direction.
■
An antenna cable and converter are not supplied.
■
To prevent damage do not connect to the mains outlet until all connections are made between the devices.
HDMI IN HDMI/DVI IN
1
1
2
2
RGB IN
COMPONENT IN
AUDIO
ANTENNA
IN
AV
VIDEO
VARIABLE
AUDIO OUT
Multi-family Dwellings/Apartments
(Connect to wall antenna socket)
Single-family Dwellings /Houses
(Connect to wall jack for outdoor antenna)
Outdoor
Antenna
Wall
Antenna
Socket
RF Coaxial Wire (75 ohm)
Antenna
UHF
Signal
Amplifier
VHF
■
In poor signal areas, to achieve better picture quality it may be necessary to install a signal amplifier to the
antenna as shown above.
■
If signal needs to be split for two TVs,use an antenna signal splitter for connection.

LG 19LD310 Specifications

General

Brand	LG
Model	19LD310
Category	LCD TV
Language	English
