ENGLISH
29
SPECIFICATIONS
SPECIFICATIONS
Television System NTSC-M, ATSC, 64 & 256 QAM
Program Coverage VHF 2-13, UHF 14-69, CATV 1-135, DTV 2-69, CADTV
1-135
Panel Screen Type 22" class Wide (21.5" diagonal)
Visible diagonal size: 546 mm
Pixel Pitch 0.248 mm (H) x 0.248 mm (V)
Video Signal Max. Resolution
1920 × 1080 @ 60 Hz
Recommended Resolution
1920 × 1080 @ 60 Hz
Horizontal Frequency
30 kHz to 83 kHz
Vertical Frequency
56 Hz to 75 Hz
Synchronization Type Separate Sync, Digital
Input Connector TV, D-Sub Analog, PC Audio In, Component, AV(CVBS),
HDMI, USB
Power Rated Voltage 19 V 1.6 A
Power Consumption On Mode : 30 W (typ.)
Off Mode 0.4 W
AC/DC Adapter
Manufacturer: Lien Chang, Model: LCAP25A
Manufacturer: Honor, Model: ADS-40SG-19-2 19032G
Tilt Tilt Range -5° to 20°
Dimensions (Width x Depth x Height)
Weight
With Stand
508.6 mm x 186.7 mm x 386.6 mm
3.3 kg
Without Stand
508.6 mm x 62.9 mm x 314.8 mm
3.1 kg
Environmental
conditions
Operating Temperature
Operating Humidity
10 °C to 35 °C (50 °F to 95 °F)
20 % to 80 %
Storage Temperature
Storage Humidity
-10 °C to 60 °C (14 °F to 140 °F)
5 % to 90 %
Product specifications shown above may be changed without prior notice due to upgrade of product
functions.
