LG 26LQ630H User Manual

20
EXTERNAL EQUIPMENT SETUP
EXTERNAL EQUIPMENT SETUP
HD RECEIVER SETUP
V To prevent the equipment damage, never plug in any power cords until you have finished connecting all equipment.
V This part of EXTERNAL EQUIPMENT SETUP mainly uses the picture for 22LQ630H model.
This TV can receive Digital Over-the-air or Digital Cable signals without an external digital set-top box.
However, if you do receive digital signals from a digital set-top box or other digital external device, refer to the
figure as shown below.
EXTERNAL EQUIPMENT SETUP
HDMI Connection
1. How to connect
1
Connect the digital set-top box to HDMI/DVI IN 1
jack on the TV.
2
No separate audio connection is necessary.
HDMI supports both audio and video.
2. How to use
V Turn on the digital set-top box.
(Refer to the owner’s manual for the digital set-top box.)
V Select HDMI 1 or HDMI 2 input source with using the
INPUT button on the remote control.
HDMI-DTV
Resolution
Horizontal
Frequency(kHz)
Vertical
Frequency(Hz)
720x480p
31.47
31.47
59.94
60.00
1280x720p
44.96
45.00
59.94
60.00
1920x1080i
33.72
33.75
59.94
60.00
1920x1080p
67.50
67.432
27.00
26.97
33.75
33.71
60.00
59.939
24.00
23.976
30.00
29.97
PILLOW SPEAKER
RGB IN (PC)
RF IN
TV-LINK
CFG
AUDIO IN
(RGB/DVI)
SPEAKER
OUT(8Ω)
REMOTE
CONTROL
OUT
RS-232C IN
(SERVICE ONLY)
GAME CONTROL
/ M.P.I.
PILL
O
W
S
PEAKE
R
RGB IN
(
PC
)
RF
IN
TV
-L
INK
C
F
G
A
U
DI
O
I
N
(
RGB/DVI
)
S
PEAKER
OUT
(
8Ω
)
R
EM
O
T
E
C
ONTROL
O
UT
R
S
-2
3
2C I
N
(
SERVICE ONLY
)
GAME CONTROL
/ M.P.I
.
/DVI IN IN
1 2
HDMI-DTV OUTPUT
1
OR

LG 26LQ630H Specifications

General

Response time	6 ms
Display diagonal	26 \
Display brightness	- cd/m²
Display resolution	1366 x 768 pixels
Native aspect ratio	16:9
Native refresh rate	60 Hz
LED backlighting type	Edge-Lit LED
Contrast ratio (dynamic)	50000:1
Screen format adjustments	4:3, 16:9
Supported graphics resolutions	1366 x 768
3D	No
Cable lock slot type	Kensington
Tuner type	Analog & digital
Analog signal format system	NTSC
Digital signal format system	ATSC
Smart modes	Energy saving
Sound modes	Standard
Audio decoders	Dolby Digital
RMS rated power	5 W
Number of speakers	2
DVI-D ports quantity	0
USB 2.0 ports quantity	1
Number of OSD languages	4
On Screen Display (OSD) languages	ENG, ESP, FRE, KOR
Audio formats supported	MP3
Image formats supported	JPG
Video formats supported	DIVX, MPEG4
Product color	Black
LED indicators	Power
Panel mounting interface	100 x 100 mm
AC input voltage	120 V
AC input frequency	50 - 60 Hz
Power consumption (max)	60 W
Power consumption (standby)	1 W
Power consumption (typical)	35 W
Package depth	147 mm
Package width	742 mm
Package height	495 mm
Package weight	7303 g
Certification	UL, cUL, NOM
Sustainability certificates	RoHS, ENERGY STAR

Weight and Dimensions

Depth (without stand)	58 mm
Width (without stand)	658 mm
Height (without stand)	427 mm
Weight (without stand)	5489 g
