LG 26LQ630H User Manual

6
CONTENTS
WARNING / CAUTION . . . . . . . . . . . . . . . 2
SAFETY INSTRUCTIONS . . . . . . . . . . . . . 3
CONTENTS . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
FEATURES OF THIS TV. . . . . . . . . . . . . . . 7
PREPARATION
Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Protection Cover. . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Front Panel Information. . . . . . . . . . . . . . . . . . . . 10
Back Panel Information . . . . . . . . . . . . . . . . . . . . 12
Cable Management . . . . . . . . . . . . . . . . . . . . . . . 15
Wall Mount Installation . . . . . . . . . . . . . . . . . . . . 17
Kensington Security System . . . . . . . . . . . . . . . . 17
VESA Wall Mounting . . . . . . . . . . . . . . . . . . . . . . 18
Antenna or Cable Connection . . . . . . . . . . . . . . 19
EXTERNAL EQUIPMENT SETUP
HD Receiver Setup . . . . . . . . . . . . . . . . . . . . . . . 20
DVD Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
VCR Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Other A/V Source Setup . . . . . . . . . . . . . . . . . . . 25
Pillow Speaker Setup . . . . . . . . . . . . . . . . . . . . . . 26
PC Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
WATCHING TV / CHANNEL CONTROL
Turning On TV . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Channel Selection. . . . . . . . . . . . . . . . . . . . . . . . . 33
Volume Adjustment . . . . . . . . . . . . . . . . . . . . . . . 33
Initial Setting . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
On-Screen Menus Selection . . . . . . . . . . . . . . . . 36
Channel Setup
- Auto Scan (Auto Tuning) . . . . . . . . . . . . . . 37
- Add / Delete Channel (Manual Tuning) . . 38
- Channel Editing . . . . . . . . . . . . . . . . . . . . . . 39
Channel Label . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Input List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
PICTURE CONTROL
Picture Size (Aspect Ratio) Control . . . . . . . . . 42
Preset Picture Settings . . . . . . . . . . . . . . . . . . . . 44
Manual Picture Adjustment - User Mode . . . . . 45
Picture Improvement Technology . . . . . . . . . . . 46
Picture Reset . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
Demo Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
SOUND & LANGUAGE CONTROL
Auto Volume Leveler (Auto Volume) . . . . . . . . . 50
Clear Voice II. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
Balance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
Preset Sound Settings (Sound Mode). . . . . . . . 53
Sound Setting Adjustment - User Mode . . . . . . 54
Infinite Sound . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
TV Speakers On/Off Setup. . . . . . . . . . . . . . . . . 56
Audio Reset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
Stereo/SAP Broadcast Setup . . . . . . . . . . . . . . . 58
Audio Language . . . . . . . . . . . . . . . . . . . . . . . . . . 59
On-Screen Menus Language Selection . . . . . . . 60
Caption Mode
- Analog Broadcasting System Captions . . . 61
- Digital Broadcasting System Captions . . . 62
- Caption Option . . . . . . . . . . . . . . . . . . . . . . 63
TIME SETTING
Clock Setting
- Auto Clock Setup . . . . . . . . . . . . . . . . . . . . 64
- Manual Clock Setup . . . . . . . . . . . . . . . . . . 65
Auto On/Off Time Setting . . . . . . . . . . . . . . . . . 66
Sleep Timer Setting . . . . . . . . . . . . . . . . . . . . . . . 67
Auto Shut-Off Setting . . . . . . . . . . . . . . . . . . . . . 67
PARENTAL CONTROL / RATINGS
Set Password & Lock System . . . . . . . . . . . . . . . 68
Channel Blocking . . . . . . . . . . . . . . . . . . . . . . . . . 71
Movie & TV Rating. . . . . . . . . . . . . . . . . . . . . . . . 72
Downloadable Rating. . . . . . . . . . . . . . . . . . . . . . 75
External Input Blocking . . . . . . . . . . . . . . . . . . . . 76
USB
Entry Modes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77
Movie List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79
Photo List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83
Music List. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 87
APPENDIX
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . 90
Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 92
Product Specifications. . . . . . . . . . . . . . . . . . . . . 93
Open Source License . . . . . . . . . . . . . . . . . . . . . 94

LG 26LQ630H Specifications

General

Response time	6 ms
Display diagonal	26 \
Display brightness	- cd/m²
Display resolution	1366 x 768 pixels
Native aspect ratio	16:9
Native refresh rate	60 Hz
LED backlighting type	Edge-Lit LED
Contrast ratio (dynamic)	50000:1
Screen format adjustments	4:3, 16:9
Supported graphics resolutions	1366 x 768
3D	No
Cable lock slot type	Kensington
Tuner type	Analog & digital
Analog signal format system	NTSC
Digital signal format system	ATSC
Smart modes	Energy saving
Sound modes	Standard
Audio decoders	Dolby Digital
RMS rated power	5 W
Number of speakers	2
DVI-D ports quantity	0
USB 2.0 ports quantity	1
Number of OSD languages	4
On Screen Display (OSD) languages	ENG, ESP, FRE, KOR
Audio formats supported	MP3
Image formats supported	JPG
Video formats supported	DIVX, MPEG4
Product color	Black
LED indicators	Power
Panel mounting interface	100 x 100 mm
AC input voltage	120 V
AC input frequency	50 - 60 Hz
Power consumption (max)	60 W
Power consumption (standby)	1 W
Power consumption (typical)	35 W
Package depth	147 mm
Package width	742 mm
Package height	495 mm
Package weight	7303 g
Certification	UL, cUL, NOM
Sustainability certificates	RoHS, ENERGY STAR

Weight and Dimensions

Depth (without stand)	58 mm
Width (without stand)	658 mm
Height (without stand)	427 mm
Weight (without stand)	5489 g
