PREPARATION

DESKTOP PEDESTAL INSTALLATION

For proper ventilation, allow a clearance of 4 inches on all four sides from the wall.

■

Image shown may differ from your TV.

4 inches

SWIVEL STAND (Except 19/22LH20R, 19LU50R, 22/26LU50FR, 22LU40R, 22LD330 )

After installing the TV, you can adjust the TV manually to the left or right direction by 20 degrees to suit your

viewing position.

Ensure adequate ventilation by following the clearance recommendations.

Do not mount near or above any type of heat source.

CAUTION

POSITIONING YOUR DISPLAY (For 19/22LH20R, 22LD330)

■

Here shown may be somewhat different from your TV.

■

Adjust the position of the panel in various ways for maximum comfort.

• Tilt range

19LU50R, 22/26LU50FR

22LU40R have a fixed stand type without the tilt and swivel features so exces-

sive pressure may damage the TV.

NOTE

MFL58486305-Edit1-en- 5/28/10 2:32 PM Page 38
