1
2
2. How to use
■
Turn on the PC and the TV.
■
Select the
RRGGBB--PPCC
input source on the TV using the
IINNPPUUTT
button on the remote control.
Connect the VGA output of the PC to the
RRGGBB IINN
((
PPCC
))
jack on the TV.
Connect the PC audio output to the
AAUUDDIIOO IINN
((
RRGGBB//DDVVII
))
jack on the TV.
1. How to connect
2
1
GG
19/22/26/32/37/42LH20R, 19LU50R,
22LU40R, 22/26/32LD330, 32LD340,
26/32LD331C: To get the best picture
quality, adjust the PC graphics card to
1360x768.
GG
32/42LF20FR, 32/37/42/47LH30FR,
22/26LU50FR, 42/47/55LH50YR,
32/42/47LH70YR, 42/47LH90QR,
32/42/47/55SL80YR, 42/47SL90QR,
32/42LD410, 32/42LD420: To get the
best picture quality, adjust the PC graphics
card to 1920x1080.
GG
In PC mode, there may be noise associated
with the resolution, vertical pattern, contrast
or brightness. If noise is present, change the
PC output to another resolution, change
the refresh rate to another rate or adjust the
brightness and contrast on the PICTURE
menu until the picture is clear.
GG
Avoid keeping a fixed image on the screen
for a long period of time. The fixed image
could become permanently imprinted on
the screen.
GG
The synchronization input form for Horizontal
and Vertical frequencies is separate.
GG
Depending on the graphics card, some res-
olution settings may not allow the image to
be positioned on the screen properly.
NOTES
