ENGLISH_index
61
79. [MultiScreen Mode & Input] (Command: x c)
Saves or controls the MultiScreen Mode and input.
Transmission
(x)(c)( )(Set ID)( )(Data1)( )(Data2)( )(Data3( )(Data4)
( )(Data5)( )Cr)
Data1 (sets the MultiScreen Mode)
10: PIP
22: PBP2
23: PBP3
24: PBP4
Data2 (sets the MultiScreen Main Input)
Data3 (sets the MultiScreen Sub1 Input)
Data4 (sets the MultiScreen Sub2 Input)
Data5 (sets the MultiScreen Sub3 Input)
20: AV
40: COMPONENT
60: RGB
80: DVI-D
90: HDMI1
91: HDMI2/OPS
92: OPS/HDMI3/DVI-D
95: OPS/DVI-D
96: HDMI3/DVI-D
98: OPS
C0: DISPLAYPORT
Acknowledgement
(c)( )(Set ID)( )(OK/NG)( )(Data1)(Data2)(Data3)
(Data4)(Data5)(x)
* This feature may not be supported in certain models.
* Only the input modes supported by the model works.
* This feature operates as the last input, and supports data in DTV
format.
80. [Aspect Ratio] (MultiScreen) (Command: x d)
Saves or controls the Aspect Ratio (MultiScreen) screen.
Transmission
(x)(d)( )(Set ID)( )(Data1)( )(Data2)(Cr)
Data1 01: Controls the Main input
02: Controls the Sub1 input
03: Controls the Sub2 input
04: Controls the Sub3 input
Data2 00: Full
01: Original
Acknowledgement
(d)( )(Set ID)( )(OK/NG)(Data1)(Data2)(x)
* This feature may not be supported in certain models.
81. [Screen Mute] (MultiScreen) (Command: x e)
Turns on/off each screen in MultiScreen.
Transmission
(x)(e)( )(Set ID)( )(Data1)( )(Data2)(Cr)
Data1 01: Controls the Main input
02: Controls the Sub1 input
03: Controls the Sub2 input
04: Controls the Sub3 input
Data2 00: Turns the screen on.
01: Turns the screen off.
* This function works when the Multi Screen App is running.
* This function may not work properly if there is no signal.
Acknowledgement
(e)( )(Set ID)( )(OK/NG)(Data1)(Data2)(x)
* This feature may not be supported in certain models.
82. [Screen Off Always] (Command: s n, 0d)
Screen Off Always has the same effect as entering the Screen Off menu
regardless of the PM Mode setting.
Transmission
(s)(n)( )(Set ID)( )(0)(d)( )(Data)(Cr)
Data 00: Off
01: On
Acknowledgement
(n)( )(Set ID)( )(OK/NG)(0)(d)(Data)(x)
* This feature may not be supported in certain models.
83. [Screen Video Freeze] (Command: k x)
Turns on/off the video freeze function.
Transmission
(k)(x)( )(Set ID)( )(Data)(Cr)
Data 00: Turns on the freeze function.
01: Turns off the freeze function.
* Available in single input mode.
Acknowledgement
(x)( )(Set ID)( )(OK/NG)(Data)(x)
* This feature may not be supported in certain models.
